دیتاشیت LT7101MPUHE#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LT7101 |
|---|---|
| حجم فایل | 3206.706 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 38 |
دانلود دیتاشیت LT7101 |
LT7101 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Analog Devices LT7101MPUHE#TRPBF
- Output Type: Adjustable
- Input Voltage: 4.4V~105V
- Output Voltage: 1V~105V
- Number of Outputs: 1
- Switching Frequency: 2MHz
- Output Current (Max): 1A
- Operating Temperature: -55°C~+150°C@(TA)
- Synchronous Rectification: Yes
- Package: QFN-36-EP(5x6)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 4.4V
- Voltage - Input (Max): 105V
- Voltage - Output (Min/Fixed): 1V
- Voltage - Output (Max): 105V
- Current - Output: 1A
- Frequency - Switching: 200kHz ~ 2MHz
- Synchronous Rectifier: Yes
- Mounting Type: Surface Mount
- Package / Case: 36-WFQFN, 26 Leads, Exposed Pad
- Supplier Device Package: 36-QFN (5x6)
- detail: Buck Switching Regulator IC Positive Adjustable 1V 1 Output 1A 36-WFQFN, 26 Leads, Exposed Pad
