LTC7000(-1) Datasheet Datasheet

LTC7000(-1) Datasheet

Datasheet specifications

Datasheet's name LTC7000(-1) Datasheet
File size 1988.177 KB
File type pdf
Number of pages 30

Download Datasheet LTC7000(-1) Datasheet

Download Datasheet

Other documentations

LTC7000EMSE#TRPBF 30 pages

Technical specifications

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Analog Devices LTC7000MPMSE#PBF
  • Fall Time: 40ns
  • Load Type: MOSFET
  • Rise Time: 90ns
  • Supply Voltage: 3.5V~135V
  • Number of Drivers: 1
  • Driven Configuration: High Side
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Package: MSOP-16-EP
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Channel Type: Single
  • Gate Type: N-Channel MOSFET
  • Voltage - Supply: 3.5V ~ 15V
  • Logic Voltage - VIL, VIH: -
  • Current - Peak Output (Source, Sink): -
  • Input Type: Non-Inverting
  • High Side Voltage - Max (Bootstrap): 135V
  • Rise / Fall Time (Typ): 90ns, 40ns
  • Mounting Type: Surface Mount
  • Package / Case: 16-TFSOP (0.118", 3.00mm Width) Exposed Pad
  • Supplier Device Package: 16-MSOP-EP
  • Base Part Number: LTC7000
  • detail: High-Side Gate Driver IC Non-Inverting 16-MSOP-EP
