دیتاشیت SI8221CC-D-IS
مشخصات دیتاشیت
| نام دیتاشیت |
SI8220/21
|
| حجم فایل |
1546.047
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
31
|
مشخصات
-
Manufacturer:
Silicon Labs
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Rise / Fall Time (Typ):
30ns, 30ns (Max)
-
Number of Channels:
1
-
Approval Agency:
CQC, CSA, UR, VDE
-
Pulse Width Distortion (Max):
-
-
Technology:
Capacitive Coupling
-
Voltage - Forward (Vf) (Typ):
2.5V (Max)
-
Current - Peak Output:
500mA
-
Series:
Automotive, AEC-Q100
-
Voltage - Output Supply:
12.2V ~ 24V
-
Operating Temperature:
-40°C ~ 125°C
-
Common Mode Transient Immunity (Min):
30kV/µs (Typ)
-
Current - DC Forward (If) (Max):
30mA
-
Current - Output High, Low:
300mA, 500mA
-
Propagation Delay tpLH / tpHL (Max):
60ns, 40ns
-
Part Status:
Active
-
Voltage - Isolation:
3750Vrms
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
8-SOIC
-
Packaging:
Tube
-
detail:
500mA Gate Driver Capacitive Coupling 3750Vrms 1 Channel 8-SOIC
