دیتاشیت C8051F350-GQR

C8051F35x Datasheet

مشخصات دیتاشیت

نام دیتاشیت C8051F35x Datasheet
حجم فایل 4622.997 کیلوبایت
نوع فایل pdf
تعداد صفحات 234

دانلود دیتاشیت C8051F35x Datasheet

C8051F35x Datasheet Datasheet

مشخصات

  • RoHS: true
  • EEPROM: -
  • CPU Core: 51Series
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • RAM Size: 768Byte
  • Watchdog: Yes
  • ADC (Bit): 24bit
  • DAC (Bit): 8bit
  • Datasheet: SILICON LABS C8051F350-GQR
  • PWM (Bit): -
  • Real-Time Clock: -
  • CPU Maximum Speed: 50MHz
  • GPIO Ports Number: 17
  • Low-Voltage Detect: Yes
  • CCP Capture/Compare: -
  • Internal Comparator: -
  • Internal Oscillator: Yes
  • Peripheral/Function: PWM;WDT
  • Program Memory Type: FLASH
  • Direct Memory Access: -
  • Program Storage Size: 8KB
  • Universal Serial Bus: -
  • communication protocol: -
  • Operating Voltage Range: 2.7V~3.6V
  • Infrared Data Association: -
  • Operating Temperature Range: -40°C~+85°C
  • Secure Digital Input and Output: -
  • Package: TQFP-32(7x7)
  • Manufacturer: SILICON LABS
  • Package / Case: 32-LQFP
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Speed: 50MHz
  • Core Processor: 8051
  • Series: C8051F35x
  • Base Part Number: C8051F35
  • Data Converters: A/D 8x24b; D/A 2x8b
  • Connectivity: SMBus (2-Wire/I²C), SPI, UART/USART
  • Mounting Type: Surface Mount
  • EEPROM Size: -
  • Number of I/O: 17
  • Oscillator Type: Internal
  • Supplier Device Package: 32-LQFP (7x7)
  • Program Memory Size: 8KB (8K x 8)
  • Part Status: Active
  • Core Size: 8-Bit
  • Voltage - Supply (Vcc/Vdd): 2.7V ~ 3.6V
  • Peripherals: POR, PWM, Temp Sensor, WDT
  • Packaging: Cut Tape (CT)
  • detail: 8051 C8051F35x Microcontroller IC 8-Bit 50MHz 8KB (8K x 8) FLASH 32-LQFP (7x7)
