دیتاشیت MCP8026-115E/MP
مشخصات دیتاشیت
| نام دیتاشیت | MCP8025,26 Datasheet |
|---|---|
| حجم فایل | 2765.575 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 65 |
دانلود دیتاشیت MCP8025,26 Datasheet |
MCP8025,26 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Type: 无刷直流BLDC
- Category: Power Supply Chip/Motor Driver ICs
- Datasheet: Microchip Tech MCP8026-115E/MP
- Interface: PWM
- Supply Voltage: 6V~28V
- Operating Temperature: -40°C~+150°C@(Ta)
- Package: QFN-40-EP(5x5)
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Tube
- Part Status: Active
- Motor Type - Stepper: -
- Motor Type - AC, DC: Brushless DC (BLDC)
- Function: Controller - Commutation, Direction Management
- Output Configuration: Pre-Driver - Half Bridge (3)
- Technology: NMOS, PMOS
- Step Resolution: -
- Applications: General Purpose
- Current - Output: -
- Voltage - Supply: 6V ~ 28V
- Voltage - Load: -
- Mounting Type: Surface Mount
- Package / Case: 40-VFQFN Exposed Pad
- Supplier Device Package: 40-QFN (5x5)
- Base Part Number: MCP8026
- detail: Motor Driver NMOS, PMOS PWM 40-QFN (5x5)
