دیتاشیت EFM8SB10F8A-A-QFN20
مشخصات دیتاشیت
| نام دیتاشیت | EFM8SB1 Datasheet |
|---|---|
| حجم فایل | 1236.897 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 71 |
دانلود دیتاشیت EFM8SB1 Datasheet |
EFM8SB1 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: -
- CPU Core: 51Series
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 512Byte
- Watchdog: -
- ADC (Bit): 12bit
- DAC (Bit): -
- Datasheet: SILICON LABS EFM8SB10F8A-A-QFN20
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 25MHz
- GPIO Ports Number: 13
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: PWM
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 8KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.8V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+125°C
- Secure Digital Input and Output: -
- Package: QFN-20-EP(3x3)
- Manufacturer: SILICON LABS
- Number of I/O: 13
- EEPROM Size: -
- Speed: 25MHz
- Supplier Device Package: 20-QFN (3x3)
- Package / Case: 20-UFQFN Exposed Pad
- Core Processor: CIP-51 8051
- Series: Automotive, AEC-Q100, Sleepy Bee
- Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
- Operating Temperature: -40°C ~ 125°C (TA)
- Oscillator Type: Internal
- Program Memory Size: 8KB (8K x 8)
- Mounting Type: Surface Mount
- Part Status: Active
- Data Converters: A/D 9x12b
- Packaging: Tube
- Connectivity: I²C, SMBus, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, POR, PWM, WDT
- Core Size: 8-Bit
- detail: CIP-51 8051 Automotive, AEC-Q100, Sleepy Bee Microcontroller IC 8-Bit 25MHz 8KB (8K x 8) FLASH 20-QFN (3x3)
