دیتاشیت EZR32WG330F256R69G-C0

مشخصات دیتاشیت

دانلود دیتاشیت EZR32WG330 Datasheet	EZR32WG330 Datasheet Datasheet

RoHS: true
Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
Data Rate: 1Mbps
Datasheet: SILICON LABS EZR32WG330F256R69G-C0
Interface: I2C,SPI,UART,USART,USB
Applications: 802.15.4
Frequency Range: 142MHz~1.05GHz
Receive Current: 11.1mA
Operating Voltage: 1.98V~3.8V
Operating Temperature: -40°C~+85°C
Current Of Transmitting: 44.5mA
Package: QFN-64-EP(9x9)
Manufacturer: SILICON LABS
Modulation: 4FSK, 4GFSK, FSK, GFSK, GMSK, MSK, OOK
GPIO: 38
Data Rate (Max): 1Mbps
Sensitivity: -133dBm
Protocol: EZRadioPro
Power - Output: 20dBm
Package / Case: 64-VFQFN Exposed Pad
Current - Receiving: 11.1mA ~ 13.7mA
Series: EZR32WG
Voltage - Supply: 1.98V ~ 3.8V
Supplier Device Package: 64-QFN (9x9)
RF Family/Standard: 802.15.4
Mounting Type: Surface Mount
Current - Transmitting: 44.5mA ~ 88mA
Type: TxRx + MCU
Part Status: Active
Frequency: 142MHz ~ 1.05GHz
Memory Size: 256kB Flash, 32kB RAM
Serial Interfaces: I²C, SPI, UART, USART, USB
detail: IC RF TxRx + MCU 802.15.4 EZRadioPro 142MHz ~ 1.05GHz 64-VFQFN Exposed Pad
