LTC3118MPFE#TRPBF دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت LTC3118EUFD#PBF	دانلود دیتاشیت

مستندات دیگری یافت نشد!

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Buck-boost type
Topology: Step-down-Boost
Datasheet: Analog Devices LTC3118MPFE#TRPBF
Output Type: Adjustable
Input Voltage: 2.2V~18V
Output Voltage: 2V~18V
Number of Outputs: 1
Switching Frequency: 1.2MHz
Output Current (Max): 2A
Operating Temperature: -55°C~+150°C@(TJ)
Synchronous Rectification: Yes
Package: TSSOP-28-EP
Manufacturer: Analog Devices
Series: -
Packaging: Tube
Part Status: Obsolete
Output Configuration: Positive
Voltage - Input (Min): 2.2V
Voltage - Input (Max): 18V
Voltage - Output (Min/Fixed): 2V
Voltage - Output (Max): 18V
Current - Output: 2A
Frequency - Switching: 1.2MHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 24-WFQFN Exposed Pad
Supplier Device Package: 24-QFN (5x4)
detail: Buck-Boost Switching Regulator IC Positive Adjustable 2V 1 Output 2A 24-WFQFN Exposed Pad
