دیتاشیت LTC2257IUJ-14#TRPBF

LTC2256/57/58-14

مشخصات دیتاشیت

نام دیتاشیت LTC2256/57/58-14
حجم فایل 1382.01 کیلوبایت
نوع فایل pdf
تعداد صفحات 34

دانلود دیتاشیت LTC2256/57/58-14

LTC2256/57/58-14 Datasheet

مشخصات

  • Manufacturer: Linear Technology/Analog Devices
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Number of Bits: 14
  • Sampling Rate (Per Second): 40M
  • Number of Inputs: 1
  • Input Type: Differential
  • Data Interface: LVDS - Parallel, Parallel
  • Configuration: S/H-ADC
  • Ratio - S/H:ADC: 1:1
  • Number of A/D Converters: 1
  • Architecture: Pipelined
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 1.7V ~ 1.9V
  • Voltage - Supply, Digital: 1.7V ~ 1.9V
  • Features: -
  • Operating Temperature: -40°C ~ 85°C
  • Package / Case: 40-WFQFN Exposed Pad
  • Supplier Device Package: 40-QFN (6x6)
  • Mounting Type: Surface Mount
  • Base Part Number: LTC2257
  • detail: 14 Bit Analog to Digital Converter 1 Input 1 Pipelined 40-QFN (6x6)
