دیتاشیت LTC2323IUFD-16#TRPBF

LTC2323-16

مشخصات دیتاشیت

نام دیتاشیت LTC2323-16
حجم فایل 1342.41 کیلوبایت
نوع فایل pdf
تعداد صفحات 26

دانلود دیتاشیت LTC2323-16

LTC2323-16 Datasheet

مشخصات

  • Manufacturer: Linear Technology/Analog Devices
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Number of Bits: 16
  • Sampling Rate (Per Second): 5M
  • Number of Inputs: 2
  • Input Type: Differential, Pseudo-Differential
  • Data Interface: LVDS - Serial, Serial
  • Configuration: S/H-ADC
  • Ratio - S/H:ADC: 1:1
  • Number of A/D Converters: 2
  • Architecture: SAR
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 3.13V ~ 3.47V, 5V
  • Voltage - Supply, Digital: 3.13V ~ 3.47V, 5V
  • Features: Simultaneous Sampling
  • Operating Temperature: -40°C ~ 85°C
  • Package / Case: 28-WFQFN Exposed Pad
  • Supplier Device Package: 28-QFN (4x5)
  • Mounting Type: Surface Mount
  • Base Part Number: LTC2323
  • detail: 16 Bit Analog to Digital Converter 2 Input 2 SAR 28-QFN (4x5)
