- AT86RF233 Datasheet
AT86RF233-ZUS Datasheet
Datasheet specifications
| Datasheet's name | AT86RF233 Datasheet |
|---|---|
| File size | 4588.559 KB |
| File type | |
| Number of pages | 225 |
Download Datasheet AT86RF233 Datasheet |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Microchip Technology
- Series: -
- Packaging: Tray
- Part Status: Obsolete
- Type: TxRx + MCU
- RF Family/Standard: 802.15.4, General ISM > 1GHz
- Protocol: 6LoWPAN, Zigbee®
- Modulation: O-QPSK
- Frequency: 2.4GHz
- Data Rate (Max): 2Mbps
- Power - Output: 4dBm
- Sensitivity: -101dBm
- Memory Size: 128B SRAM
- Serial Interfaces: SPI
- Voltage - Supply: 1.8V ~ 3.6V
- Current - Receiving: 11.3mA ~ 11.8mA
- Current - Transmitting: 7.2mA ~ 13.8mA
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Surface Mount
- Package / Case: 32-VFQFN Exposed Pad
- Supplier Device Package: 32-QFN (5x5)
- Base Part Number: AT86RF233
- detail: IC RF TxRx + MCU 802.15.4, General ISM > 1GHz 6LoWPAN, Zigbee® 2.4GHz 32-VFQFN Exposed Pad
