دیتاشیت LTC2345HUK-18#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC2345-18 Datasheet |
|---|---|
| حجم فایل | 1926.853 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 40 |
دانلود دیتاشیت LTC2345-18 Datasheet |
LTC2345-18 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Analog Devices LTC2345HUK-18#TRPBF
- Interface: serial;SPI
- resolution: 18Bit
- Supply Voltage: 5V
- differential input: Yes
- number of channels: 8
- sampling frequency: 200kHz
- Operating Temperature: -40°C~+125°C
- Package: QFN-48-EP(7x7)
- Manufacturer: Analog Devices
- Series: SoftSpan™
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Number of Bits: 18
- Sampling Rate (Per Second): 200k
- Number of Inputs: 8
- Input Type: Differential
- Data Interface: LVDS - Serial, SPI
- Configuration: S/H-MUX-ADC
- Ratio - S/H:ADC: 8:1
- Number of A/D Converters: 1
- Architecture: SAR
- Reference Type: External, Internal
- Voltage - Supply, Analog: 5V
- Voltage - Supply, Digital: 5V
- Features: Simultaneous Sampling
- Package / Case: 48-WFQFN Exposed Pad
- Supplier Device Package: 48-QFN (7x7)
- Mounting Type: Surface Mount
- Base Part Number: LTC2345
- detail: 18 Bit Analog to Digital Converter 8 Input 1 SAR 48-QFN (7x7)
