دیتاشیت LTC2386CUH-16#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC2386-16 Datasheet |
|---|---|
| حجم فایل | 1110.139 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
دانلود دیتاشیت LTC2386-16 Datasheet |
LTC2386-16 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Analog Devices LTC2386CUH-16#TRPBF
- Interface: serial
- resolution: 16Bit
- Supply Voltage: 2.375V~2.625V;5V
- differential input: Yes
- number of channels: 1
- sampling frequency: 10MHz
- Operating Temperature: 0°C~+70°C
- Package: QFN-32-EP(5x5)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Number of Bits: 16
- Sampling Rate (Per Second): 10M
- Number of Inputs: 1
- Input Type: Differential
- Data Interface: LVDS - Serial
- Configuration: S/H-ADC
- Ratio - S/H:ADC: 1:1
- Number of A/D Converters: 1
- Architecture: SAR
- Reference Type: External, Internal
- Voltage - Supply, Analog: 2.375V ~ 2.625V, 5V
- Voltage - Supply, Digital: 2.375V ~ 2.625V, 5V
- Features: -
- Package / Case: 32-WFQFN Exposed Pad
- Supplier Device Package: 32-QFN (5x5)
- Mounting Type: Surface Mount
- Base Part Number: LTC2386
- detail: 16 Bit Analog to Digital Converter 1 Input 1 SAR 32-QFN (5x5)
