LTC2203, LTC2202 Datasheet دیتاشیت

LTC2203, LTC2202 Datasheet

مشخصات دیتاشیت

نام دیتاشیت LTC2203, LTC2202 Datasheet
حجم فایل 1490.385 کیلوبایت
نوع فایل pdf
تعداد صفحات 32

دانلود دیتاشیت LTC2203, LTC2202 Datasheet

دانلود دیتاشیت

سایر مستندات

LTC2203CUK#PBF 32 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Analog Devices LTC2203IUK#TRPBF
  • Interface: Parallel
  • resolution: 16Bit
  • Supply Voltage: 3.135V~3.465V
  • differential input: Yes
  • number of channels: 1
  • sampling frequency: 25MHz
  • Operating Temperature: -40°C~+85°C
  • Package: QFN-48-EP(7x7)
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • Number of Bits: 16
  • Sampling Rate (Per Second): 25M
  • Number of Inputs: 1
  • Input Type: Differential
  • Data Interface: Parallel
  • Configuration: S/H-ADC
  • Ratio - S/H:ADC: 1:1
  • Number of A/D Converters: 1
  • Architecture: Pipelined
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 3.135V ~ 3.465V
  • Voltage - Supply, Digital: 3.135V ~ 3.465V
  • Features: PGA
  • Package / Case: 48-WFQFN Exposed Pad
  • Supplier Device Package: 48-QFN (7x7)
  • Mounting Type: Surface Mount
  • Base Part Number: LTC2203
  • detail: 16 Bit Analog to Digital Converter 1 Input 1 Pipelined 48-QFN (7x7)
