دیتاشیت LTC2266CUJ-14#PBF

LTC2266/67/68-14

مشخصات دیتاشیت

نام دیتاشیت LTC2266/67/68-14
حجم فایل 699.691 کیلوبایت
نوع فایل pdf
تعداد صفحات 32

دانلود دیتاشیت LTC2266/67/68-14

LTC2266/67/68-14 Datasheet

مشخصات

  • Manufacturer: Linear Technology/Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Number of Bits: 14
  • Sampling Rate (Per Second): 80M
  • Number of Inputs: 2
  • Input Type: Differential
  • Data Interface: LVDS - Serial
  • Configuration: S/H-ADC
  • Ratio - S/H:ADC: 1:1
  • Number of A/D Converters: 2
  • Architecture: Pipelined
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 1.7V ~ 1.9V
  • Voltage - Supply, Digital: 1.7V ~ 1.9V
  • Features: Simultaneous Sampling
  • Operating Temperature: 0°C ~ 70°C
  • Package / Case: 40-WFQFN Exposed Pad
  • Supplier Device Package: 40-QFN (6x6)
  • Mounting Type: Surface Mount
  • Base Part Number: LTC2266
  • detail: 14 Bit Analog to Digital Converter 2 Input 2 Pipelined 40-QFN (6x6)
