دیتاشیت LTC2151CUJ-12#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC2152/51/50-12 |
|---|---|
| حجم فایل | 688.587 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 30 |
دانلود دیتاشیت LTC2152/51/50-12 |
LTC2152/51/50-12 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
- Datasheet: Analog Devices LTC2151CUJ-12#TRPBF
- Interface: Parallel
- resolution: 12
- Supply Voltage: 1.7V~1.9V
- number of channels: 1
- sampling frequency: 210MHz
- Operating Temperature: 0°C~+70°C
- Package: QFN-40-EP(6x6)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Number of Bits: 12
- Sampling Rate (Per Second): 210M
- Number of Inputs: 1
- Input Type: Differential
- Data Interface: LVDS - Parallel
- Configuration: S/H-ADC
- Ratio - S/H:ADC: 1:1
- Number of A/D Converters: 1
- Architecture: Pipelined
- Reference Type: External, Internal
- Voltage - Supply, Analog: 1.7V ~ 1.9V
- Voltage - Supply, Digital: 1.7V ~ 1.9V
- Features: -
- Package / Case: 40-WFQFN Exposed Pad
- Supplier Device Package: 40-QFN (6x6)
- Mounting Type: Surface Mount
- Base Part Number: LTC2151
- detail: 12 Bit Analog to Digital Converter 1 Input 1 Pipelined 40-QFN (6x6)
