LT1949-1EMS8#TR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LT1949-1
|
|
حجم فایل
|
177.268
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
8
|
مشخصات فنی
-
Manufacturer:
Linear Technology/Analog Devices
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
Function:
Step-Up, Step-Up/Step-Down
-
Output Configuration:
Positive
-
Topology:
Boost, SEPIC
-
Output Type:
Adjustable
-
Number of Outputs:
1
-
Voltage - Input (Min):
1.7V
-
Voltage - Input (Max):
12V
-
Voltage - Output (Min/Fixed):
1.7V
-
Voltage - Output (Max):
28V
-
Current - Output:
1A (Switch)
-
Frequency - Switching:
1.1MHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
-
Supplier Device Package:
8-MSOP
-
Base Part Number:
LT1949-1
-
detail:
Boost, SEPIC Switching Regulator IC Positive Adjustable 1.7V 1 Output 1A (Switch) 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
