دیتاشیت SI8450AB-B-IS1R

مشخصات دیتاشیت

دانلود دیتاشیت Si8450/51/52/55	Si8450/51/52/55 Datasheet

Manufacturer: Silicon Labs
Package / Case: 16-SOIC (0.154", 3.90mm Width)
Rise / Fall Time (Typ): 3.8ns, 2.8ns
Number of Channels: 5
Operating Temperature: -40°C ~ 125°C
Pulse Width Distortion (Max): 25ns
Data Rate: 1Mbps
Technology: Capacitive Coupling
Supplier Device Package: 16-SOIC
Series: -
Voltage - Supply: 2.7V ~ 5.5V
Isolated Power: No
Inputs - Side 1/Side 2: 5/0
Common Mode Transient Immunity (Min): 25kV/µs (Typ)
Channel Type: Unidirectional
Type: General Purpose
Propagation Delay tpLH / tpHL (Max): 35ns, 35ns
Part Status: Not For New Designs
Voltage - Isolation: 2500Vrms
Mounting Type: Surface Mount
Packaging: Tape & Reel (TR)
detail: General Purpose Digital Isolator 2500Vrms 5 Channel 1Mbps 25kV/µs (Typ) CMTI 16-SOIC (0.154", 3.90mm Width)
