LT3081 Datasheet دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LT3081 Datasheet
|
|
حجم فایل
|
474.949
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
32
|
مشخصات فنی
-
Manufacturer:
Linear Technology/Analog Devices
-
Series:
-
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Adjustable
-
Number of Regulators:
1
-
Voltage - Input (Max):
36V
-
Voltage - Output (Min/Fixed):
0V
-
Voltage - Output (Max):
34.5V
-
Voltage Dropout (Max):
1.5V @ 1.5A
-
Current - Output:
1.5A
-
Current - Quiescent (Iq):
50µA
-
Current - Supply (Max):
5mA
-
PSRR:
90dB ~ 20dB (120Hz ~ 1MHz)
-
Control Features:
Current Limit
-
Protection Features:
Over Current, Over Temperature, Reverse Polarity, Short Circuit
-
Operating Temperature:
-40°C ~ 125°C
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-7 (Formed Leads)
-
Supplier Device Package:
TO-220-7
-
Base Part Number:
LT3081
-
detail:
Linear Voltage Regulator IC 1 Output 1.5A TO-220-7
