LT3509 Datasheet دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LT3509 Datasheet
|
|
حجم فایل
|
328.032
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
24
|
مشخصات فنی
-
Manufacturer:
Linear Technology/Analog Devices
-
Series:
-
-
Part Status:
Active
-
Function:
Step-Down
-
Output Configuration:
Positive
-
Topology:
Buck
-
Output Type:
Adjustable
-
Number of Outputs:
2
-
Voltage - Input (Min):
3.6V
-
Voltage - Input (Max):
36V
-
Voltage - Output (Min/Fixed):
0.8V
-
Voltage - Output (Max):
34.2V
-
Current - Output:
700mA
-
Frequency - Switching:
260kHz ~ 2.15MHz
-
Synchronous Rectifier:
No
-
Operating Temperature:
-40°C ~ 125°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
16-TFSOP (0.118", 3.00mm Width) Exposed Pad
-
Supplier Device Package:
16-MSOP-EP
-
Base Part Number:
LT3509
-
detail:
Buck Switching Regulator IC Positive Adjustable 0.8V 2 Output 700mA 16-TFSOP (0.118", 3.00mm Width) Exposed Pad
