MIC2168AYMM دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MIC2168AYMM	دانلود دیتاشیت

MIC2168A 18 pages

RoHS: true
Category: Power Supply Chip/DC-DC Controllers
Function: Step-down type
Topology: Step-down
Datasheet: Microchip Tech MIC2168AYMM
Input Voltage: 3V~14.5V
Duty Cycle (Max): 90%
Number of Outputs: 1
Switching Frequency: 1MHz
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: MSOP-10
Manufacturer: Microchip Tech
Series: -
Packaging: Tube
Part Status: Active
Output Type: Transistor Driver
Output Configuration: Positive
Output Phases: 1
Voltage - Supply (Vcc/Vdd): 3V ~ 14.5V
Frequency - Switching: 1MHz
Synchronous Rectifier: Yes
Clock Sync: No
Serial Interfaces: -
Control Features: Current Limit, Enable
Mounting Type: Surface Mount
Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Supplier Device Package: 10-MSOP
Base Part Number: MIC2168
detail: Buck Regulator Positive Output Step-Down DC-DC Controller IC 10-MSOP
