EFM32JG12 Series دیتاشیت

EFM32JG12 Series

مشخصات دیتاشیت

نام دیتاشیت EFM32JG12 Series
حجم فایل 2229.813 کیلوبایت
نوع فایل pdf
تعداد صفحات 123

مشاهده دیتاشیت EFM32JG12 Series

دانلود دیتاشیت

سایر مستندات

EFM32JG12 Family Reference Manual 1187 pages

EFM32JG12B500F1024GL125-C 125 pages

مشخصات فنی

  • CAN: -
  • I2C: -
  • I2S: -
  • SPI: -
  • RoHS: true
  • EEPROM: -
  • CPU Core: ARM Cortex-M3
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • RAM Size: 256KB
  • Watchdog: Yes
  • ADC (Bit): 12bit
  • DAC (Bit): -
  • Datasheet: SILICON LABS EFM32JG12B500F1024IM48-CR
  • PWM (Bit): -
  • 8Bit Timer: -
  • UART/USART: -
  • 16Bit Timer: -
  • 32Bit Timer: -
  • Real-Time Clock: -
  • CPU Maximum Speed: 40MHz
  • GPIO Ports Number: 33
  • Low-Voltage Detect: Yes
  • CCP Capture/Compare: -
  • Internal Comparator: -
  • Internal Oscillator: Yes
  • Peripheral/Function: DMA;WDT;LIN(Local Interconnect Network);IrDA
  • Program Memory Type: FLASH
  • Direct Memory Access: Yes
  • Program Storage Size: 1MB
  • Universal Serial Bus: -
  • communication protocol: -
  • Operating Voltage Range: 1.8V~3.8V
  • Infrared Data Association: Yes
  • Operating Temperature Range: -40°C~+125°C
  • Secure Digital Input and Output: -
  • Package: QFN-48-EP(7x7)
  • Manufacturer: SILICON LABS
  • Number of I/O: 33
  • EEPROM Size: -
  • Speed: 40MHz
  • Supplier Device Package: 48-QFN (7x7)
  • Package / Case: 48-VFQFN Exposed Pad
  • Core Processor: ARM® Cortex®-M3
  • Series: Jade Gecko
  • Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.8V
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Oscillator Type: Internal
  • Program Memory Size: 1MB (1M x 8)
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Data Converters: A/D - 12b SAR
  • Packaging: Tray
  • Connectivity: I²C, IrDA, LINbus, SmartCard, SPI, UART/USART
  • Peripherals: Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT
  • Core Size: 32-Bit
  • detail: ARM® Cortex®-M3 Jade Gecko Microcontroller IC 32-Bit 40MHz 1MB (1M x 8) FLASH 48-QFN (7x7)
