دیتاشیت SI4431-B1-FMR

مشخصات دیتاشیت

دانلود دیتاشیت SI4430/31/32-B1	SI4430/31/32-B1 Datasheet

RoHS: true
Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
Data Rate: 256Kbps
Datasheet: SILICON LABS SI4431-B1-FMR
Interface: SPI
Applications: General-purpose ISM<1GHz
Frequency Range: 240MHz~930MHz
Receive Current: 18.5mA
Operating Voltage: 1.8V~3.6V
Operating Temperature: -40°C~+85°C
Current Of Transmitting: 17mA
Package: QFN-20(4x4)
Manufacturer: SILICON LABS
Sensitivity: -121dBm
Series: -
Voltage - Supply: 1.8V ~ 3.6V
Type: TxRx Only
Frequency: 240MHz ~ 930MHz
Mounting Type: Surface Mount
Package / Case: 20-VFQFN Exposed Pad
Modulation: FSK, GFSK, OOK
Supplier Device Package: 20-QFN (4x4)
Packaging: Tape & Reel (TR)
Data Rate (Max): 256kbps
GPIO: 3
Power - Output: 13dBm (Max)
Current - Receiving: 18.5mA
RF Family/Standard: General ISM < 1GHz
Protocol: -
Part Status: Not For New Designs
Serial Interfaces: SPI
Memory Size: -
Current - Transmitting: 17mA ~ 30mA
detail: IC RF TxRx Only General ISM < 1GHz 240MHz ~ 930MHz 20-VFQFN Exposed Pad
