دیتاشیت SI88340EC-ISR

مشخصات دیتاشیت

دانلود دیتاشیت SI88x4x Datasheet	SI88x4x Datasheet Datasheet

Manufacturer: Silicon Labs
Package / Case: 24-SOIC (0.295", 7.50mm Width)
Rise / Fall Time (Typ): 2.5ns, 2.5ns
Number of Channels: 4
Operating Temperature: -40°C ~ 125°C
Pulse Width Distortion (Max): 7ns
Data Rate: 100Mbps
Technology: Capacitive Coupling
Supplier Device Package: 24-SOIC
Series: -
Voltage - Supply: 3V ~ 5.5V
Isolated Power: No
Inputs - Side 1/Side 2: 4/0
Common Mode Transient Immunity (Min): 40kV/µs
Channel Type: Unidirectional
Type: General Purpose
Propagation Delay tpLH / tpHL (Max): 18ns, 23ns
Part Status: Active
Voltage - Isolation: 5000Vrms
Mounting Type: Surface Mount
detail: General Purpose Digital Isolator 5000Vrms 4 Channel 100Mbps 40kV/µs CMTI 24-SOIC (0.295", 7.50mm Width)
