دیتاشیت SI8284CD-IS

Si8281-84 Datasheet

مشخصات دیتاشیت

نام دیتاشیت Si8281-84 Datasheet
حجم فایل 1121.088 کیلوبایت
نوع فایل pdf
تعداد صفحات 46

دانلود دیتاشیت Si8281-84 Datasheet

Si8281-84 Datasheet Datasheet

مشخصات

  • Manufacturer: Silicon Labs
  • Package / Case: 24-SOIC (0.295", 7.50mm Width)
  • Rise / Fall Time (Typ): 5.5ns, 8.5ns
  • Number of Channels: 1
  • Approval Agency: CQC, CSA, UR, VDE
  • Pulse Width Distortion (Max): 5ns
  • Technology: Capacitive Coupling
  • Voltage - Forward (Vf) (Typ): -
  • Current - Peak Output: 4A
  • Series: -
  • Voltage - Output Supply: 12V ~ 30V
  • Operating Temperature: -40°C ~ 125°C
  • Common Mode Transient Immunity (Min): 35kV/µs
  • Current - Output High, Low: 2.5A, 3A
  • Propagation Delay tpLH / tpHL (Max): 50ns, 50ns
  • Part Status: Not For New Designs
  • Voltage - Isolation: 5000Vrms
  • Mounting Type: Surface Mount
  • Supplier Device Package: 24-SOIC
  • Packaging: Tube
  • detail: 4A Gate Driver Capacitive Coupling 5000Vrms 1 Channel 24-SOIC
