- دیتاشیت EFR32FG13P231F512GM32-DR
EFR32FG13P231F512GM32-DR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | EFR32FG13P231F512GM32-DR |
|---|---|
| حجم فایل | 91.969 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 195 |
دانلود دیتاشیت EFR32FG13P231F512GM32-DR |
دانلود دیتاشیت |
|---|
سایر مستندات
EFR32xG13 Reference Manual 1221 pages
EFR32FG13 195 pages
مشخصات فنی
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
- Datasheet: SILICON LABS EFR32FG13P231F512GM32-DR
- Package: QFN-32-EP(5x5)
- Manufacturer: SILICON LABS
- Operating Temperature: -40°C ~ 85°C (TA)
- Sensitivity: -103.3dBm
- Series: Flex Gecko
- Voltage - Supply: 1.8V ~ 3.8V
- Type: TxRx + MCU
- Frequency: 169MHz ~ 170MHz, 195MHz ~ 358MHz, 426MHz ~ 445MHz, 470MHz ~ 510MHz, 863MHz ~ 876MHz, 902MHz ~ 930MHz
- Mounting Type: Surface Mount
- Package / Case: 32-VFQFN Exposed Pad
- Modulation: 2-FSK, 4-FSK, ASK, BPSK, DBPSK, DSSS, GFSK, GMSK, MSK, OOK, O-QPSK
- Supplier Device Package: 32-RQFN (5x5)
- Packaging: Tape & Reel (TR)
- Data Rate (Max): 2Mbps
- GPIO: 16
- Power - Output: 20dBm
- Current - Receiving: 8.4mA ~ 14mA
- RF Family/Standard: 802.15.4, General ISM < 1GHz
- Protocol: Flex Gecko
- Part Status: Active
- Serial Interfaces: I²C, I²S, SPI, IrDA, UART, USART
- Memory Size: 512kB Flash, 64kB RAM
- Current - Transmitting: 8.5mA ~ 134.3mA
- detail: IC RF TxRx + MCU 802.15.4, General ISM < 1GHz Flex Gecko 169MHz ~ 170MHz, 195MHz ~ 358MHz, 426MHz ~ 445MHz, 470MHz ~ 510MHz, 863MHz ~ 876MHz, 902MHz ~ 930MHz 32-VFQFN Exposed Pad
