MCP23017-E/SSVAO Datasheet

MCP23017, MCP23S17 Datasheet

Datasheet specifications

Datasheet's name MCP23017, MCP23S17 Datasheet
File size 865.289 KB
File type pdf
Number of pages 42

Download Datasheet MCP23017, MCP23S17 Datasheet

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: Microchip Technology
  • Series: Automotive, AEC-Q100
  • Packaging: Tube
  • Part Status: Active
  • Number of I/O: 16
  • Interface: I²C
  • Interrupt Output: Yes
  • Features: POR
  • Output Type: Open Drain
  • Current - Output Source/Sink: 25mA
  • Clock Frequency: 10MHz
  • Voltage - Supply: 4.5V ~ 5.5V
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: 28-SSOP (0.209", 5.30mm Width)
  • Supplier Device Package: 28-SSOP
  • Base Part Number: MCP23017
  • detail: I/O Expander 16 I²C 10MHz 28-SSOP
