دیتاشیت TC4424AVMF-VAO

TC4423A-25A

مشخصات دیتاشیت

نام دیتاشیت TC4423A-25A
حجم فایل 775.671 کیلوبایت
نوع فایل pdf
تعداد صفحات 22

دانلود دیتاشیت TC4423A-25A

TC4423A-25A Datasheet

مشخصات

  • Manufacturer: Microchip Technology
  • Series: Automotive, AEC-Q100
  • Packaging: Tube
  • Part Status: Active
  • Driven Configuration: Low-Side
  • Channel Type: Independent
  • Number of Drivers: 2
  • Gate Type: N-Channel, P-Channel MOSFET
  • Voltage - Supply: 4.5V ~ 18V
  • Logic Voltage - VIL, VIH: 0.8V, 2.4V
  • Current - Peak Output (Source, Sink): 4.5A, 4.5A
  • Input Type: Non-Inverting
  • Rise / Fall Time (Typ): 12ns, 12ns
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 8-VDFN Exposed Pad
  • Supplier Device Package: 8-DFN-S (4.92x5.99)
  • Base Part Number: TC4424A
  • detail: Low-Side Gate Driver IC Non-Inverting 8-DFN-S (4.92x5.99)
