دیتاشیت MCP19119T-E/MQVAO
مشخصات دیتاشیت
نام دیتاشیت | MCP19118,19 Datasheet |
---|---|
حجم فایل | 2184.622 کیلوبایت |
نوع فایل | |
تعداد صفحات | 226 |
دانلود دیتاشیت MCP19118,19 Datasheet |
MCP19118,19 Datasheet Datasheet |
---|
مشخصات
- Manufacturer: Microchip Technology
- Series: Automotive, AEC-Q100
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Output Type: Transistor Driver
- Function: Step-Down
- Output Configuration: Positive
- Topology: Buck
- Number of Outputs: 1
- Output Phases: 1
- Voltage - Supply (Vcc/Vdd): 4.5V ~ 40V
- Frequency - Switching: 100kHz ~ 1.6MHz
- Duty Cycle (Max): -
- Synchronous Rectifier: Yes
- Clock Sync: No
- Serial Interfaces: I²C, PMBus, SMBus
- Control Features: Phase Control
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 28-VFQFN Exposed Pad
- Supplier Device Package: 28-QFN (5x5)
- Base Part Number: MCP19119
- detail: Buck Regulator Positive Output Step-Down I²C, PMBus, SMBus DC-DC Controller IC 28-QFN (5x5)
