EFR32xG13 Reference Manual دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت EFR32xG13 Reference Manual	دانلود دیتاشیت

EFR32FG13 195 pages

RoHS: true
Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
Data Rate: 2Mbps
Datasheet: SILICON LABS EFR32FG13P231F512IM48-DR
Interface: I2C,I2S,SPI,IrDA,UART,USART
Applications: 802.15.4,General-purpose ISM<1GHz
Frequency Range: 169MHz~170MHz;195MHz~358MHz;426MHz~445MHz;470MHz~510MHz;863MHz~876MHz;902MHz~930MHz
Receive Current: 8.4mA
Operating Voltage: 1.8V~3.8V
Operating Temperature: -40°C~+125°C
Current Of Transmitting: 8.5mA
Package: QFN-48-EP(7x7)
Manufacturer: SILICON LABS
Modulation: 2-FSK, 4-FSK, ASK, BPSK, DBPSK, DSSS, GFSK, GMSK, MSK, OOK, O-QPSK
GPIO: 32
Data Rate (Max): 2Mbps
Sensitivity: -103.3dBm
Protocol: Flex Gecko
Power - Output: 20dBm
Package / Case: 48-VFQFN Exposed Pad
Current - Receiving: 8.4mA ~ 14mA
Series: Flex Gecko
Voltage - Supply: 1.8V ~ 3.8V
Supplier Device Package: 48-QFN (7x7)
RF Family/Standard: 802.15.4, General ISM < 1GHz
Mounting Type: Surface Mount
Current - Transmitting: 8.5mA ~ 134.3mA
Type: TxRx + MCU
Part Status: Active
Frequency: 169MHz ~ 170MHz, 195MHz ~ 358MHz, 426MHz ~ 445MHz, 470MHz ~ 510MHz, 863MHz ~ 876MHz, 902MHz ~ 930MHz
Memory Size: 512kB Flash, 64kB RAM
Serial Interfaces: I²C, I²S, SPI, IrDA, UART, USART
detail: IC RF TxRx + MCU 802.15.4, General ISM < 1GHz Flex Gecko 169MHz ~ 170MHz, 195MHz ~ 358MHz, 426MHz ~ 445MHz, 470MHz ~ 510MHz, 863MHz ~ 876MHz, 902MHz ~ 930MHz 48-VFQFN Exposed Pad
