دیتاشیت MCP1407T-E/SNVAO

MCP1406,07

مشخصات دیتاشیت

نام دیتاشیت MCP1406,07
حجم فایل 965.757 کیلوبایت
نوع فایل pdf
تعداد صفحات 30

دانلود دیتاشیت MCP1406,07

MCP1406,07 Datasheet

مشخصات

  • Manufacturer: Microchip Technology
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Driven Configuration: Low-Side
  • Channel Type: Single
  • Number of Drivers: 1
  • Gate Type: IGBT, N-Channel, P-Channel MOSFET
  • Voltage - Supply: 4.5V ~ 18V
  • Logic Voltage - VIL, VIH: 0.8V, 2.4V
  • Current - Peak Output (Source, Sink): 6A, 6A
  • Input Type: Non-Inverting
  • Rise / Fall Time (Typ): 20ns, 20ns
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SOIC
  • Base Part Number: MCP1407
  • detail: Low-Side Gate Driver IC Non-Inverting 8-SOIC
