دیتاشیت MIC4605-1YMVAO

MIC4605

مشخصات دیتاشیت

نام دیتاشیت MIC4605
حجم فایل 1519.687 کیلوبایت
نوع فایل pdf
تعداد صفحات 34

دانلود دیتاشیت MIC4605

MIC4605 Datasheet

مشخصات

  • Manufacturer: Microchip Technology
  • Series: Automotive, AEC-Q100
  • Packaging: Tube
  • Part Status: Active
  • Driven Configuration: Half-Bridge
  • Channel Type: Independent
  • Number of Drivers: 2
  • Gate Type: N-Channel MOSFET
  • Voltage - Supply: 5.5V ~ 16V
  • Logic Voltage - VIL, VIH: 0.8V, 2.2V
  • Current - Peak Output (Source, Sink): 1A, 1A
  • Input Type: Non-Inverting
  • High Side Voltage - Max (Bootstrap): 108V
  • Rise / Fall Time (Typ): 20ns, 20ns
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SOIC
  • detail: Half-Bridge Gate Driver IC Non-Inverting 8-SOIC
