ESD8006MUTAG دیتاشیت

ESD8006MUTAG

مشخصات دیتاشیت

نام دیتاشیت ESD8006MUTAG
حجم فایل 83.802 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

مشاهده دیتاشیت ESD8006MUTAG

دانلود دیتاشیت

سایر مستندات

ESD8006 12 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: onsemi ESD8006MUTAG
  • Breakdown Voltage: 5.5V
  • Unidirectional Channels: 6
  • Maximum Clamping Voltage: 8.4V@Typ
  • Reverse Stand-Off Voltage (Vrwm): 3.3V@Max
  • Peak Pulse Current (Ipp)@10/1000us: 16A
  • Peak Pulse Power Dissipation (Ppp)@10/1000us: -
  • Package: UDFN-8
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Voltage - Reverse Standoff (Typ): 3.3V (Max)
  • Voltage - Breakdown (Min): 5.5V
  • Voltage - Clamping (Max) @ Ipp: 8.4V (Typ)
  • Current - Peak Pulse (10/1000µs): 16A
  • Power - Peak Pulse: -
  • Power Line Protection: No
  • Applications: USB
  • Capacitance @ Frequency: 0.32pF @ 1MHz
  • Operating Temperature: -55°C ~ 125°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: 10-UFDFN
  • Supplier Device Package: 8-UDFN (3.3x1.0)
  • Base Part Number: ESD80
  • detail: 8.4V (Typ) Clamp 16A Ipp Tvs Diode Surface Mount 8-UDFN (3.3x1.0)
