دیتاشیت NCP5501DT50RKG
مشخصات دیتاشیت
| نام دیتاشیت |
NCP,NCV5500,01
|
| حجم فایل |
191.809
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
13
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCP5501DT50RKG
-
Output Current:
500mA
-
Output Voltage:
5V
-
Dropout Voltage:
0.7V@(500mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
16V
-
Operating Temperature:
-40°C~+85°C
-
Quiescent Current (Ground Current):
500uA
-
Package:
TO-252
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Output Type:
Fixed
-
Number of Regulators:
1
-
Voltage - Input (Max):
16V
-
Voltage - Output (Min/Fixed):
5V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.7V @ 500mA
-
Current - Output:
500mA
-
Current - Quiescent (Iq):
500µA
-
Current - Supply (Max):
20mA
-
PSRR:
75dB ~ 70dB (120hZ ~ 10kHz)
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature, Reverse Polarity
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-252-3, DPak (2 Leads + Tab), SC-63
-
Supplier Device Package:
DPAK
-
Base Part Number:
NCP5501
-
detail:
Linear Voltage Regulator IC 1 Output 500mA DPAK
