MDB10S دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت MDB10S	دانلود دیتاشیت

RoHS: true
Category: Diodes/Bridge Rectifiers
Datasheet: onsemi MDB10S
Reverse Voltage (Vr): 1kV
Operating Temperature: -55°C~+150°C@(Tj)
Forward Voltage (Vf@If): 1.1V@1A
Peak Forward Surge Current: 30A
Reverse Leakage Current (Ir): 10uA@1kV
Average Rectified Current (Io): 1A
Package: -
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Diode Type: Single Phase
Technology: Standard
Voltage - Peak Reverse (Max): 1kV
Current - Average Rectified (Io): 1A
Voltage - Forward (Vf) (Max) @ If: 1.1V @ 1A
Current - Reverse Leakage @ Vr: 10µA @ 1000V
Mounting Type: Surface Mount
Package / Case: 4-SMD, Gull Wing
Supplier Device Package: 4-MicroDIP/SMD
Base Part Number: MDB10
detail: Bridge Rectifier Single Phase Standard 1kV Surface Mount 4-MicroDIP/SMD
