دیتاشیت MURA110T3G
مشخصات دیتاشیت
| نام دیتاشیت |
MURA105, 110T3
|
| حجم فایل |
49.868
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
4
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Diodes - Fast Recovery Rectifiers
-
Datasheet:
onsemi MURA110T3G
-
Diode Configuration:
-
-
Reverse Voltage (Vr):
100V
-
Operating Temperature:
-65°C~+175°C@(Tj)
-
Forward Voltage (Vf@If):
875mV@1A
-
Reverse Leakage Current:
2uA@100V
-
Reverse Recovery Time (trr):
30ns
-
Average Rectified Current (Io):
2A
-
Package:
SMA
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
100V
-
Current - Average Rectified (Io):
2A
-
Voltage - Forward (Vf) (Max) @ If:
875mV @ 1A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
2µA @ 100V
-
Capacitance @ Vr, F:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
DO-214AC, SMA
-
Supplier Device Package:
SMA
-
Operating Temperature - Junction:
-65°C ~ 175°C
-
Base Part Number:
MURA110
-
detail:
Diode Standard 100V 2A Surface Mount SMA
