SBAT54SLT1G دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت SBAT54SLT1G	دانلود دیتاشیت

RoHS: true
Category: Diodes/Schottky Barrier Diodes (SBD)
Datasheet: onsemi SBAT54SLT1G
Reverse Voltage (Vr): 30V
Forward Voltage (Vf@If): 800mV@100mA
Average Rectified Current (Io): 200mA
Package: SOT-23(TO-236)
Manufacturer: onsemi
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Diode Configuration: 1 Pair Series Connection
Diode Type: Schottky
Voltage - DC Reverse (Vr) (Max): 30V
Current - Average Rectified (Io) (per Diode): 200mA (DC)
Voltage - Forward (Vf) (Max) @ If: 800mV @ 100mA
Speed: Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr): 5ns
Current - Reverse Leakage @ Vr: 2µA @ 25V
Operating Temperature - Junction: 125°C (Max)
Mounting Type: Surface Mount
Package / Case: TO-236-3, SC-59, SOT-23-3
Supplier Device Package: SOT-23-3 (TO-236)
Base Part Number: BAT54
detail: Diode Array 1 Pair Series Connection Schottky 30V 200mA (DC) Surface Mount TO-236-3, SC-59, SOT-23-3
