FDG6320C دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت FDG6320C	دانلود دیتاشیت

مستندات دیگری یافت نشد!

Manufacturer: ON Semiconductor
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
FET Type: N and P-Channel
FET Feature: Logic Level Gate
Drain to Source Voltage (Vdss): 25V
Current - Continuous Drain (Id) @ 25°C: 220mA, 140mA
Rds On (Max) @ Id, Vgs: 4Ohm @ 220mA, 4.5V
Vgs(th) (Max) @ Id: 1.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 0.4nC @ 4.5V
Input Capacitance (Ciss) (Max) @ Vds: 9.5pF @ 10V
Power - Max: 300mW
Operating Temperature: -55°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: 6-TSSOP, SC-88, SOT-363
Supplier Device Package: SC-88 (SC-70-6)
Base Part Number: FDG6320
detail: Mosfet Array N and P-Channel 25V 220mA, 140mA 300mW Surface Mount SC-88 (SC-70-6)
