دیتاشیت TIP122G

مشخصات دیتاشیت

دانلود دیتاشیت TIP120-22, TIP125-27	TIP120-22, TIP125-27 Datasheet

Manufacturer: ON Semiconductor
Series: -
Packaging: Tube
Part Status: Active
Transistor Type: NPN - Darlington
Current - Collector (Ic) (Max): 5A
Voltage - Collector Emitter Breakdown (Max): 100V
Vce Saturation (Max) @ Ib, Ic: 4V @ 20mA, 5A
Current - Collector Cutoff (Max): 500µA
DC Current Gain (hFE) (Min) @ Ic, Vce: 1000 @ 3A, 3V
Power - Max: 2W
Frequency - Transition: -
Operating Temperature: -65°C ~ 150°C (TJ)
Mounting Type: Through Hole
Package / Case: TO-220-3
Supplier Device Package: TO-220AB
Base Part Number: TIP122
detail: Bipolar (BJT) Transistor NPN - Darlington 100V 5A 2W Through Hole TO-220AB
