دیتاشیت FDWS9508L-F085

FDWS9508L-F085

مشخصات دیتاشیت

نام دیتاشیت FDWS9508L-F085
حجم فایل 649.45 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت FDWS9508L-F085

FDWS9508L-F085 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: Automotive, AEC-Q101, PowerTrench®
  • Packaging: Tape & Reel (TR)
  • Part Status: Active
  • FET Type: P-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 40V
  • Current - Continuous Drain (Id) @ 25°C: 80A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
  • Rds On (Max) @ Id, Vgs: 4.9mOhm @ 80A, 10V
  • Vgs(th) (Max) @ Id: 3V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 107nC @ 10V
  • Vgs (Max): ±16V
  • Input Capacitance (Ciss) (Max) @ Vds: 4840pF @ 20V
  • FET Feature: -
  • Power Dissipation (Max): 214W (Tj)
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 8-PQFN (5x6)
  • Package / Case: 8-PowerTDFN
  • Base Part Number: FDWS9
  • detail: P-Channel 40V 80A (Tc) 214W (Tj) Surface Mount 8-PQFN (5x6)
