NVMFS5C604NLAFT1G دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت NVMFS5C604NLAFT1G	دانلود دیتاشیت

Manufacturer: ON Semiconductor
Series: Automotive, AEC-Q101
Packaging: Cut Tape (CT)
Part Status: Active
FET Type: N-Channel
Technology: MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss): 60V
Current - Continuous Drain (Id) @ 25°C: 287A (Tc)
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Rds On (Max) @ Id, Vgs: 1.2mOhm @ 50A, 10V
Vgs(th) (Max) @ Id: 2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs: 52nC @ 4.5V
Vgs (Max): ±20V
Input Capacitance (Ciss) (Max) @ Vds: 8900pF @ 25V
FET Feature: -
Power Dissipation (Max): 200W (Tc)
Operating Temperature: -55°C ~ 175°C (TJ)
Mounting Type: Surface Mount
Supplier Device Package: 5-DFN (5x6) (8-SOFL)
Package / Case: 8-PowerTDFN, 5 Leads
Base Part Number: NVMFS5
detail: N-Channel 60V 287A (Tc) 200W (Tc) Surface Mount 5-DFN (5x6) (8-SOFL)
