- دیتاشیت MBRS4201T3G
MBRS4201T3G دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MBRS4201T3G |
|---|---|
| حجم فایل | 85.25 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 5 |
دانلود دیتاشیت MBRS4201T3G |
دانلود دیتاشیت |
|---|
سایر مستندات
SMC Pkg Drawing 1 pages
MBRS4201T3 5 pages
مشخصات فنی
- RoHS: true
- Category: Diodes/Schottky Barrier Diodes (SBD)
- Datasheet: onsemi MBRS4201T3G
- Reverse Voltage (Vr): 200V
- Forward Voltage (Vf@If): 860mV@4A
- Average Rectified Current (Io): 4A
- Package: SMC(DO-214AB)
- Manufacturer: onsemi
- Series: -
- Packaging: Tape & Reel (TR)
- Part Status: Obsolete
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 200V
- Current - Average Rectified (Io): 4A
- Voltage - Forward (Vf) (Max) @ If: 860mV @ 4A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 35ns
- Current - Reverse Leakage @ Vr: 1mA @ 200V
- Capacitance @ Vr, F: -
- Mounting Type: Surface Mount
- Package / Case: DO-214AB, SMC
- Supplier Device Package: SMC
- Operating Temperature - Junction: -55°C ~ 150°C
- Base Part Number: MBRS4201
- detail: Diode Schottky 200V 4A Surface Mount SMC
