دیتاشیت FFSH50120A
مشخصات دیتاشیت
| نام دیتاشیت |
FFSH50120A
|
| حجم فایل |
440.286
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
7
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Schottky Barrier Diodes (SBD)
-
Datasheet:
onsemi FFSH50120A
-
Diode Configuration:
Single
-
Reverse Voltage (Vr):
1.2kV
-
Forward Voltage (Vf@If):
1.45V@50A
-
Reverse Leakage Current (Ir):
200uA@1.2kV
-
Average Rectified Current (Io):
77A
-
Package:
TO-247-2
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Diode Type:
Silicon Carbide Schottky
-
Voltage - DC Reverse (Vr) (Max):
1200V
-
Current - Average Rectified (Io):
77A (DC)
-
Speed:
No Recovery Time > 500mA (Io)
-
Reverse Recovery Time (trr):
0ns
-
Current - Reverse Leakage @ Vr:
200µA @ 1200V
-
Capacitance @ Vr, F:
2560pF @ 1V, 100kHz
-
Mounting Type:
Through Hole
-
Package / Case:
TO-247-2
-
Supplier Device Package:
TO-247-2
-
Operating Temperature - Junction:
-55°C ~ 175°C
-
Base Part Number:
FFSH50
-
detail:
Diode Silicon Carbide Schottky 1200V 77A (DC) Through Hole TO-247-2
