دیتاشیت 1N4148-T50R
مشخصات دیتاشیت
| نام دیتاشیت | 1N91x, 1N4x48, FDLL914, FDLL4x48 |
|---|---|
| حجم فایل | 154.753 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 7 |
دانلود دیتاشیت 1N91x, 1N4x48, FDLL914, FDLL4x48 |
1N91x, 1N4x48, FDLL914, FDLL4x48 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Diodes/Switching Diode
- Datasheet: onsemi 1N4148-T50R
- Power Dissipation: 500mW
- Diode Configuration: -
- Reverse Voltage (Vr): 100V
- Operating Temperature: -55°C~+175°C@(Tj)
- Forward Voltage (Vf@If): 1V@10mA
- Reverse Leakage Current: 5uA@75V
- Reverse Recovery Time (trr): 4ns
- Average Rectified Current (Io): 300mA
- Package: DO-35
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 100V
- Current - Average Rectified (Io): 200mA
- Voltage - Forward (Vf) (Max) @ If: 1V @ 10mA
- Speed: Small Signal =< 200mA (Io), Any Speed
- Current - Reverse Leakage @ Vr: 5µA @ 75V
- Capacitance @ Vr, F: 4pF @ 0V, 1MHz
- Mounting Type: Through Hole
- Package / Case: DO-204AH, DO-35, Axial
- Supplier Device Package: DO-35
- Operating Temperature - Junction: 175°C (Max)
- Base Part Number: 1N4148
- detail: Diode Standard 100V 200mA Through Hole DO-35
