1N5229BTR 数据手册
其他文档
1N5221B - 63B 7 pages
技术规格
- RoHS: true
- Category: Diodes/Zener Diodes
- Datasheet: onsemi 1N5229BTR
- Tolerance: ±5%
- Power Dissipation: 500mW
- Diode Configuration: -
- Zener Voltage (Nom): 4.3V
- Zener Impedance (Zzt): 22Ω
- Zener Voltage (Range): 4.085V~4.515V
- Reverse Leakage Current (Ir): 5uA@1V
- Package: Plugin,D1.53xL3.05mm
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Voltage - Zener (Nom) (Vz): 4.3V
- Power - Max: 500mW
- Impedance (Max) (Zzt): 22 Ohms
- Current - Reverse Leakage @ Vr: 5µA @ 1V
- Voltage - Forward (Vf) (Max) @ If: 1.2V @ 200mA
- Operating Temperature: -65°C ~ 200°C
- Mounting Type: Through Hole
- Package / Case: DO-204AH, DO-35, Axial
- Supplier Device Package: DO-35
- Base Part Number: 1N5229
- detail: Zener Diode 4.3V 500mW ±5% Through Hole DO-35
