1N5242BTR Datasheet
Datasheet specifications
|
Datasheet's name
|
1N5242BTR
|
|
File size
|
97.971
KB
|
|
File type
|
pdf
|
|
Number of pages
|
6
|
Technical specifications
-
RoHS:
true
-
Category:
Diodes/Zener Diodes
-
Datasheet:
onsemi 1N5242BTR
-
Tolerance:
±5%
-
Power Dissipation:
500mW
-
Zener Voltage (Nom):
12V
-
Zener Impedance (Zzt):
30Ω
-
Reverse Leakage Current (Ir):
1uA@9.1V
-
Package:
Plugin,D1.53xL3.05mm
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Voltage - Zener (Nom) (Vz):
12V
-
Power - Max:
500mW
-
Impedance (Max) (Zzt):
30 Ohms
-
Current - Reverse Leakage @ Vr:
1µA @ 9.1V
-
Voltage - Forward (Vf) (Max) @ If:
1.2V @ 200mA
-
Operating Temperature:
-65°C ~ 200°C
-
Mounting Type:
Through Hole
-
Package / Case:
DO-204AH, DO-35, Axial
-
Supplier Device Package:
DO-35
-
Base Part Number:
1N5242
-
detail:
Zener Diode 12V 500mW ±5% Through Hole DO-35
