دیتاشیت BC818-40LT1G

مشخصات دیتاشیت

دانلود دیتاشیت BC818-40L, NSVBC818-40L	BC818-40L, NSVBC818-40L Datasheet

Manufacturer: ON Semiconductor
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Transistor Type: NPN
Current - Collector (Ic) (Max): 500mA
Voltage - Collector Emitter Breakdown (Max): 25V
Vce Saturation (Max) @ Ib, Ic: 700mV @ 50mA, 500mA
Current - Collector Cutoff (Max): 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 250 @ 100mA, 1V
Power - Max: 225mW
Frequency - Transition: 100MHz
Operating Temperature: -55°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: TO-236-3, SC-59, SOT-23-3
Supplier Device Package: SOT-23-3 (TO-236)
Base Part Number: BC818
detail: Bipolar (BJT) Transistor NPN 25V 500mA 100MHz 225mW Surface Mount SOT-23-3 (TO-236)
