دیتاشیت MMBZ6V8ALT1G
مشخصات دیتاشیت
| نام دیتاشیت | MMBZ/SZMMBZyyyALT1 Series |
|---|---|
| حجم فایل | 146.186 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 8 |
دانلود دیتاشیت MMBZ/SZMMBZyyyALT1 Series |
MMBZ/SZMMBZyyyALT1 Series Datasheet |
|---|
مشخصات
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Datasheet: TECH PUBLIC MMBZ6V8ALT1G
- Package: SOT-23(TO-236)
- Manufacturer: TECH PUBLIC
- Breakdown Voltage: 6.46V
- Bidirectional Channels: 1
- Unidirectional Channels: 2
- Maximum Clamping Voltage: 9.6V
- Reverse Stand-Off Voltage (Vrwm): 4.5V
- Peak Pulse Current (Ipp)@10/1000us: 2.5A
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 24W
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Type: Zener
- Voltage - Reverse Standoff (Typ): 4.5V
- Voltage - Breakdown (Min): 6.46V
- Voltage - Clamping (Max) @ Ipp: 9.6V
- Current - Peak Pulse (10/1000µs): 2.5A
- Power - Peak Pulse: 24W
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: -
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23-3 (TO-236)
- Base Part Number: MMBZ6V
- detail: 9.6V Clamp 2.5A Ipp Tvs Diode Surface Mount SOT-23-3 (TO-236)
