MMBZ27VALT1G دیتاشیت

MMBZ27VALT1G

مشخصات دیتاشیت

نام دیتاشیت MMBZ27VALT1G
حجم فایل 46.302 کیلوبایت
نوع فایل pdf
تعداد صفحات 4

دانلود دیتاشیت MMBZ27VALT1G

دانلود دیتاشیت

سایر مستندات

MMBZ/SZMMBZyyyALT1 Series 8 pages

MMBZ33VALT1G 7 pages

MMBZ5V6ALT1G 5 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: TECH PUBLIC MMBZ27VALT1G
  • Package: SOT-23(TO-236)
  • Manufacturer: TECH PUBLIC
  • Breakdown Voltage: 25.65V
  • Bidirectional Channels: 1
  • Unidirectional Channels: 2
  • Maximum Clamping Voltage: 40V
  • Reverse Stand-Off Voltage (Vrwm): 22V
  • Peak Pulse Current (Ipp)@10/1000us: 1A
  • Peak Pulse Power Dissipation (Ppp)@10/1000us: 40W
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Voltage - Reverse Standoff (Typ): 22V
  • Voltage - Breakdown (Min): 25.65V
  • Voltage - Clamping (Max) @ Ipp: 40V
  • Current - Peak Pulse (10/1000µs): 1A
  • Power - Peak Pulse: 40W
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: -
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Supplier Device Package: SOT-23-3 (TO-236)
  • Base Part Number: MMBZ27
  • detail: 40V Clamp 1A Ipp Tvs Diode Surface Mount SOT-23-3 (TO-236)
