دیتاشیت ESDR0502BT1G
مشخصات دیتاشیت
| نام دیتاشیت | ESDR0502B, SZESDR0502B |
|---|---|
| حجم فایل | 166.45 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 4 |
دانلود دیتاشیت ESDR0502B, SZESDR0502B |
ESDR0502B, SZESDR0502B Datasheet |
|---|
مشخصات
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Zener
- Unidirectional Channels: 2
- Bidirectional Channels: 1
- Voltage - Reverse Standoff (Typ): 5V (Max)
- Voltage - Breakdown (Min): 5.8V
- Voltage - Clamping (Max) @ Ipp: 15V
- Current - Peak Pulse (10/1000µs): 2A (8/20µs)
- Power - Peak Pulse: 20W
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: 0.5pF @ 1MHz, 0.25pF @ 1MHz
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: SC-75, SOT-416
- Supplier Device Package: SC-75, SOT-416
- Base Part Number: ESDR05
- detail: 15V Clamp 2A (8/20µs) Ipp Tvs Diode Surface Mount SC-75, SOT-416
